Enter Into The Micro-Machining World
Micro-Machining stretches your limits of design possibilities and opens new horizons for aerospace, medical, or just fundamental research and development.

• With our programmable Micro-EDM systems positioning to 1µm (.00004") is possible with holes being drilled from 10µm (.0004") and up to 1mm (040").
• Air slits are available from 10µm (.0004") width in various exotic metals.
• Typical holes now being drilled routinely are 50µm (.002") in stainless steel 1mm (.040") thickness. Tolerance +/- 1-2µm (+/- .00004" - .00008").

We also drill holes in stainless steel via laser down to 1µm (.00004") in 12µm (.0005") thickness for laser, optical and vacuum leak detection.

140µm Platinum
Photo Magnified 500X

µEDM

µEDM

50µm in Platinum
Photo Magnified 1000X

200µm Air Slit in Stainless Steel
Photo Magnified 70X

µEDM

µEDM

Precise taper angles and

depths

LASER vs. µEDM     Need We Say More!

22µm Stainless Steel
Photo Magnified 3000X

LASER

µEDM

28.5µm Molybdenym
Photo Magnified 2500X
